Once you’ve studied up on accessible features, your next steps could be to visit bathroom showrooms to see accessible products and then to mock-up your floor plan and design ideas.Īll of the photos and floor plans in this article were created in the RoomSketcher App. A shower-spray mechanism with a hose gives the user flexibility to wash, or for a caregiver to help. The shower mechanism controls should be easy to reach.
#8x12 bathroom layout portable#
The entry should ideally be 36” (915 mm) wide and flat (curbless) or close to flat at the entry point – you want the ability to wheel directly in, without a high curb.Ī fold-down bench, portable stool or fixed bench is a nice feature in the shower area.
The recommendation is generally 32” – 36” (915 mm) wide and 60” (1525 mm) deep so that it can accommodate a wheelchair as well as an extra person. Additionally, a caregiver or spouse may need to help with the bathing process, so a shower space should be generously sized. Flat and Wide Shower EntryĪn accessible bathroom often includes a shower rather than a bathtub, for easier access, and safety. Make sure that they are in a location that will be easy for the user. Finally, consider where the flush controls are for these devices. Grab bars near the toilet can also be helpful.Ī “comfort height” (taller) toilet may be easier to use and a bidet can also be helpful. Extra Space Around ToiletĪs mentioned above, it is recommended to leave a space on one side of the toilet to be able to move the wheelchair close, and for those requiring transfer assistance.
And rather than a medicine cabinet behind the sink, which could be hard to reach, consider having lower drawers for storage or a lower medicine cabinet placed in an accessible location. To make it easier to turn on the water, consider a long, single handle on the sink faucet.Ībove the sink, a tilted mirror that is slightly angled down allows the wheelchair user to see themselves more easily. A pedestal sink is another possible choice. To allow a wheelchair user to roll directly up to the sink, choose a design that has either a slant or nothing directly underneath the sink. In addition to the wheelchair circle, the floor plan example above also shows (in blue) the suggested space around the toilet for accessibility – a minimum 60-inch width space measured from the sidewall and a 56-inch space measured from the rear wall. The symbol demonstrates the clearance needed to turn the wheelchair. You may notice a circular wheelchair symbol on floor plans for accessible units. The Americans With Disabilities Act (ADA), which among other things, provides design standards to help people with disabilities, suggests turning spaces be 60” (1525 mm) in diameter. The extra space allows for easy access for a wheelchair, especially if the door is accessed from a hallway, and you’ll have to turn the wheelchair to enter.Īdditionally, a completely flat floor at the entry is best so that the wheelchair does not have to roll over a threshold or door sill.
In order to accommodate a wheelchair, the bathroom door should be at least 32” (815 mm) wide but ideally 36” (915 mm) wide. The separate room for the WC adds another layer of luxurious privacy.A standard wheelchair is 24-27” (approx. The area at the end of the bathroom forms the 'wet zone' with a seat to put clothes on (or for someone to have a chat with you in the bath) and plenty of space to dry off and not drag any water towards the vanity or the toilet area. In this bathroom layout, the bath has a luxurious surround and feels very protected – it's almost like a room in itself.
These layouts are bigger than your average bathroom, using walls to split the bathroom into sections and including large showers and luxury baths. Here's some master bathroom floor plans that will give your en suite the 5 star hotel feeling. You can find out about all the symbols used on this page on the floor plan symbols page and there's also bathroom dimensions information. This page forms part of the bathroom layout series. If you’ve got a small space take a look at the small bathroom floor plans I’ve drawn up. Obviously it's not likely that your layout will end up exactly like any of these but they will get you thinking about the possibilities. I’ve put together some master bathroom floor plans to inspire your own bathroom layout.
